EWM Phoenix 355 Expert 2.0 puls MM
Produktnummer: 090-005445-00502
Lagerbeholdning:
inkl. mva.
Multiprocess MIG/MAG pulse welding machine with MULTIMATRIX technology, compact, portable, modular, Expert 2.0 control
- Compact inverter welding machine with integrated wire feed mechanism
- Expert 2.0 control with intuitive user guidance via LCD panel and plain text display of all welding parameters and functions
- Welding procedures and functions
- Equipped at no extra charge with EWM Synergic characteristics for forceArc, forceArc puls, rootArc, rootArc puls and superPuls
- Equipped at no extra charge with Synergic characteristics for GMAW welding of steel/CrNi/aluminium
- Suitable for MMA welding, TIG welding and gouging at no extra charge
- rootArc –
- Short arc with good modelling properties for easy gap-bridging and positional welding
- ForceArc –
- Low-heat, directionally stable and powerful arc with deep penetration for the upper power range
- Pulsed arc –
- Controlled, short circuit-proof pulsed arc for all positions, especially in the transitional arc area
- Individually configurable programs for each welding task (JOB)
- Adjustable start and end-crater functions
- Infinitely adjustable arc dynamics (choke effect)
- Synergic or manual welding operation
- Your benefits
- No need to purchase additional characteristics – all characteristics for this machine type are included in the scope of delivery ex works
- Gas cooled or optionally water cooled with cool 50 U40 cooling unit
- High-precision, powerful EWM eFeed 4-roll wire feed mechanism for secure feeding of all solid and flux cored wires
- Equipped with 1.0–1.2 mm UNI rolls for low to high-alloy steel
- Wire spool diameter up to 300 mm/D300, 200 mm/D200 possible with adapter
- High open circuit voltage for excellent ignition characteristics
- Energy-saving thanks to high efficiency and standby function
- Connection capability for remote control and function torch
- Easy, tool-free change of welding polarity
- Insulated wire space
- IP23 spray water protected
| Egenskaper | |
|---|---|
| Merke | EWM |
| Lengde | 482.0 mm |
| Bredde | 298.0 mm |
| Salgsenhet | Stk |
